Description
Dual Passive LPG
双被动低通门
It’s a dual 1-pole vactrol based LPG / VCA module that only takes 2 HP space. It is totally passive, no power required. The electronic components values are carefully picked to be musical and beautiful, by feeding it a trigger you get a the lovely natural decay of a vactrol. Fill all your blank spaces in your system with this very useful and handy little module. This kit contains SMD parts.
Meng Qi does not provide a build document for this module.
BOM
1 x Panel
1x PCB
4 x 390R Resistors (0805)
2 x 15nf Ceramic Capacitors (0805 )
6 x Thonkiconn Jacks
2 x 3mm LEDs
2 x 1N4148 (SOD-123)
2 x Vactrol
2 x LED Standoff 9mm
