Distorted Light is a 22HP dual stereo resonator and reverb using 2 x BTDR digital reverb bricks. The two reverb channels feedback into each other via 2 x Vactrols, creating a lovely mess of feedback.
All panel controls interact with each other allowing for endless variations of swirling and smudgy distorted echos. In the heart of the module is a “resonator” where the two bricks influence each other using white LED’s, ping-ponging between them.
Distorted Light – Build Document & Manual
All SMD parts are already pre-soldered
