Description

Start programming the Daisy without breadboarding! The Pod is a USB powered breakout board for the Daisy. With stereo line level I/O, MIDI input and headphone output with a dedicated volume control, this is the feature-packed, small-form breakout to get started with for development. Comes with Daisy installed.

Features:

• USB Powered
• 3.5mm stereo jacks for line level audio I/O, headphone output, and TRS MIDI input.
• Built In headphone amplifier with dedicated volume control.
• 2 Buttons, 2 RGB LEDs, and rotary encoder with push button.
• SD Card Slot, and secondary USB micro port

Note: Powering the Pod from a computer may induce hum from a ground loop. We recommend using a USB power brick or comparable power source for best audio performance.

Documentation, and examples are hosted on the Electrosmith GitHub repository for easy download. All firmware that they develop is released for free under a permissive open source license(MIT). Check out the getting started wiki page!

Electrosmith – Daisy Wiki | Github
